Model 522.2

Wheel arrangement

4x4

Engine

MMZ D-245.5, diesel with turbocharging

Capacity, kW (h.p.)

66 (90)

Cylinder number

4

Gearbox

Dry disc, number og gear 14/ 4

Flywheel clutch

dry, single-disk

Min annd max speed FWD/BWD, km/h

2,08- 29,9 / 4,39- 9,88

Front axle

new type, with planetary spur reduction gears

Rear PTO shaft indep. I:II, r.p.m.

I -540 ; II -1000

Rear PTO synchronized, r.p.m. route section

3,36

Load capacity of back suspension gear, kg, min

4000 (monoblock with 2 hydrocylinders)

Overall dimensions, mm

Length

4000

Width

1970

Height

2850

 Wheel base, mm

2450

Clearance, mm

510

Operating weight, kg

4100

Tyres

Front

360/70R24

Rear

18,4R34

Additional options

Back wheel doubling, balance weight front/back, conditioner, reducing gear
